A Quick and Easy Guide to Off-Grid Solar LED Lighting Systems

May 03, 2023

Blog Team

Solar LED lighting systems that operate off the grid are typically set up outdoors and rely on solar panels to provide light. This eco-friendly option is ideal for enhancing the brightness of your outdoor space during important events.

Nevertheless, individuals who are unfamiliar with solar panels or LED lighting systems that don't require an electrical grid may have limited knowledge about the setup. Therefore, this blog aims to educate you on the fundamentals of solar LED lighting systems.

Take note of the tips provided to properly execute your DIY LED lighting project outdoors, whether it be for your home or building.

Some Basic Terms and Ultimate Guide to Off-Grid Solar LED Lighting System

  • Watt measures the power consumed by a lighting device, such as a lamp or bulb. LEDs have lower power consumption than other types of lighting systems.
  • Lumen measures the amount of light given off by a lighting device. Different devices will have different lumen measurements.
  • Foot Candle represents the amount of light given off by a lighting device from one foot of its parameter.
  • The Kelvin Kº Measurement refers to the intensity or lower degree of light emitted from a lighting device. Different spaces may require different colors of light, such as brighter light for kitchens and offices, and darker shades for living rooms or bedrooms.
  • The Color Rendition Index (CRI) measures how realistically objects appear in front of a given lighting system, whether it is LED or another type of lighting.

Outdoor Light Set-up

  • Solar Panels:

The primary component of a solar LED lighting system is the solar panel that captures the energy from the sun and converts it into electrical energy.

  • Battery:

The battery stores the electrical energy generated by the solar panel during the daytime, which is used to power the LED lights during the night.

  • Charge Controller:

A charge controller is essential to prevent overcharging and undercharging of the battery. It regulates the voltage and current flowing between the solar panel and the battery.

  • LED Lights:

LED lights are energy-efficient and long-lasting. They are perfect for outdoor lighting and consume less energy than traditional incandescent bulbs.

  • Wiring:

Wiring connects all the components of the solar LED lighting system and ensures smooth and efficient operation.

Installation Steps for an Off-Grid Solar LED Lighting System:

  • Determine the location of the solar panel and ensure that it receives direct sunlight throughout the day.
  • Install the solar panel and secure it in place.
  • Connect the charge controller to the solar panel and battery.
  • Install the battery and connect it to the charge controller.
  • Connect the LED lights to the battery.
  • Test the system for ensuring that it is working accurately.

Variations in Off-Grid Solar Lighting System

Off-grid solar lighting systems come in different variations, which are as follows:

  • Photovoltaic lights gather energy from the sun and store it in batteries PV lights generate electricity without being connected to the grid
  • Hybrid solar lights have two types of systems:
    • One uses solar modules with no battery and sends excess power into the grid
    • The other has a solar module, battery, and lighting system to generate power and operate for specific hours.

The third hybrid system generates 100% of its power and can use the grid for additional security.

The above-mentioned tips provided shall help you to properly implement your DIY LED lighting project outdoors, whether it be for your home or building. Utilize solar energy to its best.
